Diamond FL06 LED Flood Light
One Model, Multiple Power & CCT Options
FL06 LED Flood Light for Outdoor Industrial & Commercial Projects
Cost-Effective · Energy Saving · Ideal for Bulk Supply
Designed for Efficient Outdoor Lighting
The iShineLux FL06 LED Flood Light is a reliable and economical solution for outdoor industrial, commercial, and public lighting projects. Suitable for parking lots, warehouses, building facades, yards, pathways, and security areas, it delivers bright illumination, flexible settings, and long-term durability.
With adjustable power and CCT options, the FL06 helps reduce inventory pressure and purchasing costs, making it an excellent choice for wholesalers, distributors, and project contractors.
| No. | Version One | Version Two | Version Three |
| 1 | Single Power+Single CCT | Tri-Powers+Single CCT | Tri-Powers&CCTs |
🔧 Key Features
- High Efficiency Output
Up to 140 lm/W for bright lighting with lower energy consumption. - Flexible Power & CCT Options
Tri-Power + Single CCT or Tri-Power & Tri-CCT available for multiple project needs. - Cost-Saving Design
One model covers different wattages and color temperatures, reducing stock complexity and procurement costs. - Durable Outdoor Construction
ADC12 die-cast aluminum housing with IP66 waterproof protection for reliable outdoor use. - Adjustable Beam Angles
60° / 90° beam options for area lighting, facades, pathways, and general outdoor applications. - Rotatable Mounting Bracket
Easy installation with precise lighting angle adjustment. - Wide Operating Temperature
Stable performance from -25°C to +45°C in different climates.
Power & CCT Adjustable via DIP Switch – Reduce SKUs, Adapt to Any LED Flood Light Project Easily
📩 Ready to Wholesale LED Flood Lights or Quote for a Project? — Contact iShineLux Today.
⚙️ Why Choose iShineLux for Bulk LED Flood Light Supply?
✅ Factory-Direct Pricing
No middlemen. Save more with direct-from-manufacturer wholesale rates.
✅ OEM Branding Support
Customized logos and packaging to help distributors grow their brand.
✅ Fast Production & Delivery
800,000 units/year capacity. Ship within 15–20 days for most orders.
✅ Reliable Quality Assurance
All floodlights backed by a 5-year warranty for long-term performance.
Technical Specification
| Model No. | ISL-FL06-30W | ISL-FL06-50W | ISL-FL06-100W | ISL-FL06-150W | ISL-FL06-200W | ISL-FL06-250W | ISL-FL06-300W |
| Power | 30W | 50W | 100W | 150W | 200W | 250W | 300W |
| Dimmension | 199*172*37mm | 224*180*37mm | 276*228*41mm | 307*244*43mm | 385*305*44mm | 457*366*44mm | 457*366*44mm |
| Light Efficiency (±5%) | 140lm/W | ||||||
| Beam Angle | 60°/90° | ||||||
| Input Voltage | 120-277VAC, 50/60Hz | ||||||
| CCT | 3000K/ 4000K/ 5000K/ 5700K/ 6500K | ||||||
| CRI | 70 | ||||||
| LED | Lumileds/ San’an | ||||||
| Driver | iShineLux | ||||||
| IP Rating | IP66 | ||||||
| IK Rating | IK08 | ||||||
| Operation Temperature | ﹣25°C- +45°C | ||||||
| Lifespan | 50,000H | ||||||
| Warranty | 3/ 5Years | ||||||
Technical Specification - 3CCT& 3Power Adjustable
| Model No. | ISL-FL06-50W | ISL-FL06-100W | ISL-FL06-150W | ISL-FL06-200W | ISL-FL06-250W | ISL-FL06-300W | |
| Dimmension | 224*180*37mm | 276*228*41mm | 307*244*43mm | 385*305*44mm | 457*366*44mm | 457*366*44mm | |
| 3-Power& 3-CCT | 3-Power | 50W-40W-30W | 100W-80W-60W | 150W-120W-90W | 200W-160W-120W | 240W-200W-150W | 300W-240W-180W |
| 3-CCT | 3000K-4000K-5700K | ||||||
| Beam Angle | 60°/90° | ||||||
| 3-Power& single CCT | 3-Power | 50W-40W-30W | 100W-80W-60W | 150W-120W-90W | 200W-160W-120W | 240W-200W-150W | 300W-240W-180W |
| CCT | 3000K/ 4000K/ 5000K/ 5700K/ 6500K | ||||||
| Beam Angle | 60°/90° | ||||||
| Light Efficiency (±5%) | 140lm/W | ||||||
| Input Voltage | 100-277VAC, 50/60Hz | ||||||
| CRI | 70 | ||||||
| LED | Lumileds | ||||||
| Driver | iShineLux | ||||||
| IP Rating | IP66 | ||||||
| IK Rating | IK08 | ||||||
| Operation Temperature | ﹣25°C- +45°C | ||||||
| Lifespan | 50,000H | ||||||
| Warranty | 5Years | ||||||
