Skywing SF10 LED Sports Light
SF10 Sports Light
Our round-shape LED floodlights are engineered for sports stadiums, arenas, and large outdoor venues. Featuring an ultra-narrow beam angle, they deliver powerful long-distance illumination, ensuring professional-grade lighting performance for demanding projects.
The visor design minimizes qlare and spill light, while precise angle adjustment provides accurate light direction and easier on-site commissioning.
Key Features:
- Power Range: 400W-1350W
- High Efficiency: 150 lm/W
- Optical Distribution: Narrow (10°/15°), Medium (25°/45°), Wide (60°/90°)
- Flexible Driver Options: Removable aluminum driver box or lP66 individual driver, mountable on the bracket or pole for reduced fixture weight and easier maintenance
- Integrated Die-Cast Heat Sink: Large one-piece desian ensures excellent thermal management and extended lifetime
- Copper Breather Valve: Balances internal and external temperature and humidity for long-term stability
- Tempered Glass Cover Optional: Withstands harsh enyironmental conditions
- Double Surge Protection: Driver-level protection plus extra 10KV SPD
- Durability: IP66 waterproof and lK08 impact resistant for reliable outdoor performance
- Warranty: 5 years
This floodlight offers high efficiency, advanced optics, and superior durability, making it the ideal choice for stadiums, airports, ports, and other large-scale outdoor projects.
Versatile Applications
This Sports Light is specifically engineered for a wide range of outdoor sports and activity illumination needs, making it ideal for:
- Soccer Fields and Stadiums: Provides high-intensity, uniform lighting to ensure optimal visibility for players and spectators during night games.
- Tennis Courts and Basketball Courts: Delivers bright and even illumination, enhancing the playing experience and safety for athletes.
- University Sports Grounds and Athletic Facilities: Offers reliable lighting for training sessions, matches, and large-scale sports events.
- Community Sports Centers and Recreational Areas: Enhances the usability of outdoor sports facilities after dark, promoting community engagement and physical activity.
- Rugby Fields and Cricket Grounds: Ensures clear visibility for fast-paced games, supporting both competitive matches and casual play.
- Track and Field Arenas: Provides consistent lighting for running tracks, long jump pits, and other field events, ensuring safety and performance.
- Golf Courses: Illuminates key areas of the golf course, allowing golfers to enjoy the game even after sunset.
Baseball Diamonds: Delivers focused lighting for home plate, pitcher’s mound, and outfield, enhancing visibility for players and umpires.
Technical Specification
| Model No. | ISL-SF10-A-400W | ISL-SF10-A-500W | ISL-SF10-A-600W | ISL-SF10-A-800W | ISL-SF10-A-1000W | ISL-SF10-A-1200W | ISL-SF10-A-1350W |
| Power | 400W | 500W | 600W | 800W | 1000W | 1200W | 1350W |
| Dimmension | 522*509*389mm | 681*660*497mm | |||||
| Input Voltage | 100-277VAC, 50/60Hz | ||||||
| Light Efficiency (±5%) | 150lm/W | ||||||
| CCT | 3000K/ 4000K/ 5000K/ 5700K/ 6500K | ||||||
| CRI | 80 | ||||||
| Beam Angle | 10°/ 15°/ 25°/ 45°/ 60°/ 90° | ||||||
| LED | Lumileds/ Osram | ||||||
| Driver | Sosen/ MOSO (DALI, DMX) | ||||||
| SPD | 10KV | ||||||
| Options | Tempering Glass Cover | ||||||
| Housing | Die-casting technology by ADC12 | ||||||
| IP Rating | IP66 | ||||||
| IK Rating | IK08 | ||||||
| Operation Temperature | ﹣35°C- +50°C | ||||||
| Lifespan | 50,000H | ||||||
| Warranty | 5Years | ||||||
