Skywing SF11 LED Sports Light







SF11 Sports Light
Our modular LED floodlights are designed for large outdoor venues, sports facilities, ports, and industrial projects. With a power range from 400W to 2400W, they deliver exceptional performance and flexibility for different applications.
Key Features:
- Power Range: 400W-2400W (400W-600W per module)
- High Efficiency: 150 lm/W
- Optical Distribution: Narrow (10°/15°), Medium (25°/45°), Wide (60°/90°), Asymmetric (ASY60°)
- Die-Cast Heat Sink: Oversized one-piece design ensures superior thermal management and long lifespan
- Module Gap Design: Reduces wind resistance and enhances heat dissipation performance
- Copper Breather Valve: Balances internal and external pressure, preventing moisture buildup
- Double Surge Protection: Driver-level protection plus extra 10KV SPD for reliable operation
- Durability: lP66 waterproof and lK08 impact resistant, suitable for harsh outdoor environments
- Warranty: 5 years
With modular flexibility, high lumen output, and rugged construction, this floodlight is the perfect solution for stadiums, airports, harbors, and other demanding outdoor projects
Versatile Applications
This Sports Light is specifically engineered for a wide range of outdoor sports and activity illumination needs, making it ideal for:
- Soccer Fields and Stadiums: Provides high-intensity, uniform lighting to ensure optimal visibility for players and spectators during night games.
- Tennis Courts and Basketball Courts: Delivers bright and even illumination, enhancing the playing experience and safety for athletes.
- University Sports Grounds and Athletic Facilities: Offers reliable lighting for training sessions, matches, and large-scale sports events.
- Community Sports Centers and Recreational Areas: Enhances the usability of outdoor sports facilities after dark, promoting community engagement and physical activity.
- Rugby Fields and Cricket Grounds: Ensures clear visibility for fast-paced games, supporting both competitive matches and casual play.
- Track and Field Arenas: Provides consistent lighting for running tracks, long jump pits, and other field events, ensuring safety and performance.
- Golf Courses: Illuminates key areas of the golf course, allowing golfers to enjoy the game even after sunset.
Baseball Diamonds: Delivers focused lighting for home plate, pitcher’s mound, and outfield, enhancing visibility for players and umpires.
Technical Specification
Model No. | ISL-SF11-A-400W | ISL-SF11-A-500W | ISL-SF11-A-600W | ISL-SF11-A-800W | ISL-SF11-A-1000W | ISL-SF11-A-1200W | ISL-SF11-A-1500W | ISL-SF11-A-1800W | ISL-SF11-A-2000W | ISL-SF11-A-2400W |
Power | 400W | 500W | 600W | 800W | 1000W | 1200W | 1500W | 1800W | 2000W | 2400W |
Dimmension | 775*290*230mm | 775*420*393mm | 775*535*547mm | 775*613*717mm | ||||||
Input Voltage | 100-277VAC, 50/60Hz | |||||||||
Light Efficiency (±5%) | 150lm/W | |||||||||
CCT | 3000K/ 4000K/ 5000K/ 5700K/ 6500K | |||||||||
CRI | 80 | |||||||||
Beam Angle | 10°/ 15°/ 25°/ 45°/ 60°/ 90°/ 65*40*40° | |||||||||
LED | Lumileds/ Osram | |||||||||
Driver | Sosen/ MOSO (DALI, DMX) | |||||||||
SPD | 10KV | |||||||||
Housing | Die-casting technology by ADC12 | |||||||||
IP Rating | IP66 | |||||||||
IK Rating | IK08 | |||||||||
Operation Temperature | ﹣35°C- +50°C | |||||||||
Lifespan | 50,000H | |||||||||
Warranty | 5Years |
