Skywing SF18 LED Sports Light
SF18 Sports Light
SF18 Sports Lights are engineered for professional stadium lighting and large-scale outdoor sports applications. Featuring power options from 500W to 1350W, high luminous efficacy up to 180 lm/W, and multiple precision optical distributions, the SF18 delivers excellent lighting uniformity, reduced glare, and reliable performance for football fields, tennis courts, sports arenas, and high mast lighting projects.
Performance Highlights
✔ Available from 500W to 1350W for stadiums, sports fields, and large outdoor lighting projects.
✔ Up to 160 lm/W standard and 180 lm/W optional for enhanced energy savings.
✔ Multiple beam angles (10° / 15° / 25° / 45° / 60° / 90°) for optimized light distribution.
✔ Advanced optics improve visibility while minimizing glare and light spill.
✔ Heavy-Duty Die-Cast Aluminum Housing & U-Bracket for Superior Strength and Secure Installation.
✔ IP66 Outdoor Protection – Reliable operation in rain, dust, humidity, and harsh outdoor environments.
✔ Ideal for Sports Lighting Projects – Suitable for football fields, tennis courts, sports arenas, golf courses, and high mast lighting installations.
Applications
Engineered for professional sports lighting and high mast applications, delivering uniform illumination for a wide range of outdoor sports venues.
- Football Fields & Stadiums
- Tennis & Padel Courts
- Sports Arenas & Athletic Facilities
- Rugby & Cricket Grounds
- Track & Field Stadiums
- Golf Courses & Driving Ranges
- Baseball & Softball Fields
- High Mast & Outdoor Area Lighting
Technical Specification
| Model No. | ISL-SF18-500W | ISL-SF18-600W | ISL-SF18-800W | ISL-SF18-1000W | ISL-SF18-1200W | ISL-SF18-1350W |
| Power | 500W | 600W | 800W | 1000W | 1200W | 1350W |
| Dimmension | 530*429mm | 662*478mm | ||||
| Input Voltage | 100-277VAC/ 200-480VAC | |||||
| Light Efficiency (±5%) | 160lm/W (standard), 180lm/W (optional) | |||||
| CCT | 3000K/ 4000K/ 5000K/ 5700K/ 6500K | |||||
| CRI | 80 | |||||
| Beam Angle | 10°/ 15°/ 25°/ 45°/ 60°/ 90° | |||||
| LED | SMD 3030 | |||||
| Driver | Sosen/ Moso | |||||
| SPD | 10KV | |||||
| Housing | Die-casting technology by ADC12 | |||||
| IP Rating | IP66 | |||||
| IK Rating | IK08 | |||||
| Installation | Bracket Mounting/ Suspended Mounting | |||||
| Operation Temperature | ﹣20°C- +50°C | |||||
| Lifespan | 50,000H | |||||
| Warranty | 5Years | |||||
